MODEL
|
KPP-35
|
|
SUITABLE MATERIAL
|
P.P.
|
|
FILM THICKNESS
|
0.02-0.10 mm
|
|
FILM WIDTH RANGE
|
300 mm
|
|
FILM OUTPUT
|
12-18 kgs/hr
|
|
EXTRUDER UNIT
|
|
SCREW DIAMETER/TYPE
|
Ø 35 mm
|
|
SCREW L/D RATIO
|
28:1
|
|
HEATING CAPACITY
|
6 kw
|
|
AUTO THERMO CONTROL
|
3 zone
|
|
BARREL COOLING FAN
|
1/16 HP x 1
|
|
DRIVING MOTOR
|
AC 10 HP
+ Inverter
|
|
DIE UNIT
|
|
DIE DIAMETER
|
Ø120 mm
|
|
AIR RING DIAMETER
|
Ø200 mm
|
|
HEATING CAPACITY
|
2.6 kw
|
|
AUTO THERMO CONTROL
|
2 zone
|
|
COOLING BLOWER
|
1 HP
|
|
WATER RING
|
10 pcs
|
|
TAKE-UP UNIT
|
|
TAKE-UP ROLLER
|
400 mm
|
|
EFFECTIVE WIDTH
|
300 mm
|
|
TAKE-UP MOTOR
|
AC 1/2 HP
|
|
TAKE-UP SPEED
|
40 m/min
|
|
WINDING UNIT
|
|
ROLLER WIDTH
|
400 mm
|
|
WINDING WIDTH
|
300 mm
|
|
WINDING MOTOR
|
DC 1／2 HP
|
|
MACHINE DIMENSION
|
300x100x350 cm
|
* Remark: The above machine specification and production range can be changed without any notice due to kind of different application.
